Tennant/Nobles - 4041585 - Bushing, Sleeve, 0.62B 0.72D 0.50L, Fgl (Replaces Tennant 07449)

Tennant 4041585 is a fiberglass sleeve bushing with a 0.62 in (15.7 mm) bore, a 0.72 in (18.3 mm) outside diameter and a length of 0.50 in (12.7 mm), also listed as 07449. The description reads Bushing, Sleeve, 0.62B 0.72D 0.50L, Fgl.

The Tennant catalog lists it in these groups: the Directional Pedal Group of the 800 sweepers, 1 per machine, and the Rear Squeegee Linkage Group of the 7400 (Ford engine) and 7400D rider scrubbers, 4 per machine. Parts manuals in the fitment index include the M20, M30, T20, 275-II, 810D, 6100 and 255. Check the group on your drawing for the exact count.
