| Models | MiniMag Edge 28" |
| Cleaning Path | 28 in (71 cm) |
| Edge Pad Size | (1) 28 x 14 in |
| Edge Pad Motor | 1.0 hp (780 W), 2,000 or 2,500 rpm |
| Brush Down Pressure | 0-150 lb (0-68 kg) |
| Solution Tank | 17 gal (64 L) |
| Recovery Tank | 17 gal (64 L) |
| Solution Flow | 0-1.0 gpm (0-4 L/min) |
| Vacuum Motor | 0.75 hp (559 W) |
| Vacuum Lift / Airflow | 70 in (178 cm) / 70 cfm |
| Demisting Chamber | 1.25 gal (5 L) |
| Drain Saver | 30 cu in |
| Battery System | 24 V; 155 Ah standard, 225 Ah optional |
| Run Time | Up to 4 hr |
| Charger | Dual-mode console, 110 V / 60 Hz |
| Drive | 0.75 hp (559 W), all gear, sealed |
| Speed | Forward 0-230 ft/min; reverse 0-130 ft/min |
| Size (L x W x H) | 45 x 18 x 40 in (114 x 46 x 102 cm) |
| Weight | 255 lb (116 kg) without batteries; 387 lb (176 kg) with batteries |
| Sound Level | 67 dBA |
| Model Numbers | MiniMag 28-Edge |
Technical specs may include optional equipment that is not included with all units.
Reconditioned Tomcat MiniMag Edge 28" Orbital Traction Drive Floor Scrubber
Our Take (from the SES Sales Team)
“The MiniMag Edge 28 is the widest Edge version of Tomcat's mid-size walk-behind. In place of a round disk it runs Tomcat's Edge orbital head, a 28 x 14-inch rectangular pad driven at high speed by a 1.0 hp motor. Tomcat built it to strip floor finish with water and a prep pad instead of chemical stripper, and to wet-screen wood gym floors.
What stands out is the combination: traction drive through a 0.75 hp all-gear transaxle, up to 150 lb of down pressure, and 17 gallons each of solution and recovery on a 24-volt system. The square pad corners reach baseboards better than a round pad, and the oscillating head keeps water under the pad instead of throwing it outward.
The trade-off: the Edge head runs rectangular pads, so round pads won't carry over, and it doesn't sweep. For routine daily scrubbing alone, a disk scrubber is the simpler choice, and narrow rooms may suit the 24-inch Edge better. This listing is a reconditioned unit.”
A 28-inch orbital traction-drive scrubber for chemical-free stripping.
The Tomcat MiniMag Edge 28 is a battery-powered walk-behind scrubber with a 28-inch Edge orbital scrub deck and traction drive, and this listing is a reconditioned unit. A 1.0 hp (780 W) motor oscillates the 28 x 14 in pad at 2,000 or 2,500 rpm with up to 150 lb of down pressure, which Tomcat designed for removing floor finish with water instead of chemical stripper.
It carries 17 gal (64 L) of solution and 17 gal (64 L) of recovery. A 0.75 hp vacuum motor rated at 70 in of water lift and 70 cfm recovers the water through a 1.25 gal demisting chamber. The 24 V system uses a 155 Ah battery pack as standard for up to 4 hours of run time, and a 0.75 hp all-gear transaxle drives the machine.
Condition: Refurbished (Reconditioned). See how we recondition equipment.
Features
- ✓28 x 14 in Edge orbital pad on a 1.0 hp motor
- ✓Strips floor finish with water instead of chemical stripper
- ✓Traction drive with a 0.75 hp all-gear transaxle
- ✓17 gal solution and 17 gal recovery tanks
- ✓Fully cleanable recovery tank with drain saver basket
Tomcat MiniMag Edge 28" Orbital Traction Drive Floor Scrubber
Specifications
| Models | MiniMag Edge 28" |
| Cleaning Path | 28 in (71 cm) |
| Brush Down Pressure | 0-150 lb (0-68 kg) |
| Solution Tank | 17 gal (64 L) |
| Recovery Tank | 17 gal (64 L) |
| Solution Flow | 0-1.0 gpm (0-4 L/min) |
| Vacuum Lift / Airflow | 70 in (178 cm) / 70 cfm |
| Weight | 255 lb (116 kg) without batteries; 387 lb (176 kg) with batteries |
| Sound Level | 67 dBA |
| Model Numbers | MiniMag 28-Edge |
Technical specs may include optional equipment that is not included with all units.
