| Machine Type | Walk-behind battery automatic carpet extractor |
|---|---|
| Power Source | Battery (electric) |
| Cleaning Path Width | 15 in (38 cm) |
| Solution Tank Capacity | 3.5 gal (13.2 L) |
| Recovery Tank Capacity | 3.5 gal (13.2 L) |
New Tennant 1510 Battery Automatic Extractor
Our Take (from the SES Sales Team)
“The 1510 is a self-contained, battery-powered carpet extractor for hotels, casinos, offices, schools and retail spaces that want both routine and restorative carpet cleaning from one walk-behind. It has two modes. Interim surface cleaning runs at 100 ft per minute for lighter soil and shorter dry times, and deep cleaning slows to 50 ft per minute for maximum soil removal. Tennant locks in the top cleaning speed for each mode, so operators clean at the right pace without making adjustments, and starting is one button. The 21 gal solution and recovery tanks are large for a 22 in wide machine, and Tennant rates it at up to 4,500 sq ft per hour. Because it runs on four 6 V, 240 Ah batteries, there is no cord to drag across hallways or guest areas, and Tennant lists up to 3 hours of run time. Two 3-stage vacuum motors with 68 in of water lift pull the solution back. If cord power works for you, the 1530 is the corded version with a 30 gal solution tank.”
A cord-free walk-behind carpet extractor with two modes
The Tennant 1510 is a battery-powered, self-contained walk-behind carpet extractor for hotels, casinos, offices, schools and retail spaces. Deep cleaning mode removes the most soil, and interim surface cleaning mode gives shorter dry times, with one-button start and locked-in cleaning speeds.
This is the complete Tennant 1510 package: four 6 V, 240 Ah batteries and a 20 A charger, with the 21 gal solution tank, 100 psi solution pump and dual vacuum motors.
Condition: New.
What you get
A complete, cord-free package
Accessory tools
Features
Simple for any operator
- ✓One-button start for less operator training
- ✓Locked-in top cleaning speeds keep operators at the proper pace
- ✓Interim mode at 100 ft/min, deep mode at 50 ft/min
- ✓Dual nylon brushes agitate the carpet
- ✓Compact 22 in wide body for doorways and hallways
Battery or cord?
Tennant 1510 or 1530?
| 1510 battery (this unit) | 1530 cord electric | |
|---|---|---|
| Power | 4 x 6 V, 240 Ah batteries | 75 ft (22.9 m) power cord |
| Run time | Up to 3 hr | No battery limit |
| Solution tank | 21 gal (79 L) | 30 gal (114 L) |
| Vacuum motors | 2 x 3-stage, 0.89 hp; 68 in water lift | 1 x 3-stage, 1.63 hp; 117 in water lift |
| Weight | 656 lb with batteries (298 kg) | 395 lb (180 kg) |
Both share the 19 in cleaning path, 21 gal recovery tank, 100 psi pump and two cleaning modes.
Specifications
Tennant 1510 at a glance
| Models | 1510 Battery Extractor |
|---|---|
| Cleaning path | 19 in (482 mm) |
| Productivity | Up to 4,500 sq ft/hr (418 m²) |
| Brush motors | 2 x 0.2 hp (0.15 kW) |
| Brush type | Nylon |
| Solution / recovery tanks | 21 gal (79 L) / 21 gal (79 L) |
| Solution pump | 100 psi max (6.9 bar) |
| Solution flow rate | 1 gpm (3.8 L/min) |
| Vacuum motors | 2 x 3-stage, 0.89 hp (0.66 kW) |
| Vacuum airflow | 69 cfm (1.96 m³/min) |
| Water lift | 68 in (1,730 mm) |
| Cleaning speed | 100 ft/min interim (30 m/min); 50 ft/min deep (15 m/min) |
| Batteries | 4 x 6 V, 240 Ah |
| Run time | Up to 3 hr |
| Charger | 20 A |
| Sound level | 72 dBA |
| Width x height | 22 x 42 in (559 x 1,067 mm) |
| Weight | 656 lb with batteries (298 kg) |
| Model Numbers | 2206344 (Tennant 1510 battery extractor with batteries and charger) |
Technical specs may include optional equipment that is not included with all units.
Questions
Tennant 1510: common questions
What is the difference between the two cleaning modes?
Deep cleaning runs at 50 ft per minute for maximum soil removal. Interim surface cleaning runs at 100 ft per minute for routine maintenance and shorter dry times.
How long does it run on a charge?
Tennant rates the 1510 at up to 3 hours on its four 6 V, 240 Ah batteries.
How much carpet can it clean in an hour?
Tennant rates it at up to 4,500 sq ft per hour.
Will it fit through my doorways?
The 1510 is 22 in wide and 42 in high. Check your narrowest doorway and any elevator before you order.
Should I choose the 1510 or the 1530?
Pick the 1510 if cords are a problem in your building, such as guest areas or long corridors. The corded 1530 is lighter and has a larger 30 gal solution tank.
